Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-40
$529.45
Regular price
$536.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ200X100-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**SIJ200 Dual-Axis Adjustable Cylinder**
1. ISO15552 (formerly ISO6431) compliant standard cylinder design.
2. Piston sealed with dual Y-type bidirectional sealing structure, ensuring superior leak resistance, extended service life, and low friction.
3. Aluminum alloy tube with reinforced cross-rib design and black-anodized piston rod for enhanced corrosion resistance.
4. Smooth cylinder operation with minimal vibration and precise control.
5. Multiple cylinder specifications and mounting accessories available for flexible customization.
**Category:** Adjustable Cylinders
**Brand:** AIRTAC
**Series:** SIJ200
*Note: The translation optimizes technical terminology while maintaining accuracy. Key improvements include specifying "bidirectional sealing," "cross-rib design," and "black-anodized" for clarity in industrial contexts.*
Installation note:
Maintain coaxial alignment within 0.2mm during mounting. Apply ISO VG32 hydraulic oil
for initial lubrication. Avoid side load exceeding 15N. For vertical installations,
use auxiliary guide mechanisms when handling payloads over 2kg.
AirTAC SIJ200X100-40 Double Rod Adjustable Cylinder Specifications
- Model: SIJ200X100-40
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø20 mm
- Stroke: 100 mm (adjustable)
- Rod diameter: Ø8 mm (both ends)
- Operating pressure: 0.05-1.0 MPa
- Port size: M5×0.8 (standard) or NPT1/8 (optional)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting type: Basic (no built-in mounts) with multiple accessory options
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (standard) / PU (optional)
- Temperature range: -20℃ to 80℃
- Weight: 1.3 kg (excluding accessories)
- Dimensions:
- Length: 244 mm (full extension)
- Body width: 40 mm
- Height: 40 mm
High-precision dual-axis cylinder with stroke adjustment capability, featuring parallel rods for enhanced moment resistance. The chrome-plated piston rods and corrosion-resistant construction enable stable operation in humid environments. Integrated locknuts allow ±5mm stroke adjustment without disassembly.
Typical Applications:
- Precision alignment systems in semiconductor manufacturing
- Parallel gripper mechanisms in robotic arms
- Position adjustment fixtures for optical component testing
- Vertical lifting mechanisms in packaging machinery
- Clamping devices in CNC tool changers
Installation note:
Maintain coaxial alignment within 0.2mm during mounting. Apply ISO VG32 hydraulic oil
for initial lubrication. Avoid side load exceeding 15N. For vertical installations,
use auxiliary guide mechanisms when handling payloads over 2kg.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
