Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-40S
AirTAC SIJ200X100-40S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-40S
- Type: Double rod compact cylinder with adjustable stroke
- Bore size: 200 mm
- Stroke: 100 mm (±5mm adjustable)
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: 40 mm (both rods)
- Cushioning: Adjustable air cushion at both ends
- Port size: G1/8 (NPT1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (nitrile butadiene rubber)
- Mounting type: Basic (no built-in mount) with 4x M12 threaded holes
- Weight: 5.8 kg (with standard accessories)
- Dimensions:
- Body length: 280 mm
- Total extended length: 380 mm (stroke included)
- Width: 250 mm (including rod ends)
- Height: 210 mm (from base to rod centerline)
Industrial-grade dual rod cylinder engineered for precision alignment and heavy-duty applications. Features synchronized dual piston rods for enhanced rigidity and anti-rotation stability. The chrome-plated rods and anodized aluminum body provide corrosion resistance in humid environments. Stroke adjustment is achieved through external mechanical stoppers (included).
- Precision press tooling alignment systems
- Automated material clamping fixtures
- Glass handling equipment in photovoltaic production
- Vertical lifting mechanisms in packaging lines
- Precision grinding machine workholding
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
For vertical installations, use external guide mechanisms when handling
eccentric loads exceeding 50kg. Maintain 20mm clearance around cylinder
body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
