Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-50
AirTAC SIJ200X100-50 Double-Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-50
- Type: Double-axis adjustable stroke cylinder with guide rods
- Bore size: 20mm (SIJ200 series standard)
- Stroke: 100mm (adjustable)
- Rod diameter: 10mm (both guide rods)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable elastic cushion at both ends
- Port size: M5x0.8 (dual ports)
- Repeat positioning accuracy: ±0.05mm
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel
- Seal type: NBR wear-resistant seals
- Temperature range: -10℃ to 80℃
- Weight: 1.85kg (with mounting brackets)
- Dimensions:
- Length: 286mm (fully retracted)
- Width: 48mm (body width)
- Height: 54mm (including guide rods)
- Mounting options: Front flange, side mount, or base mount
Precision dual-rod cylinder designed for applications requiring high rigidity and positional accuracy. Features independent stroke adjustment screws (±2mm fine-tuning range) and anti-rotation mechanism. The chromium-plated guide rods provide exceptional lateral load capacity (max 45N·m moment resistance). Includes built-in magnet for position sensing compatibility.
- Precision clamping fixtures in CNC machining centers
- Z-axis drives in semiconductor wafer handling
- Press-fit mechanisms for electronic component assembly
- Automated optical inspection system positioners
- Packaging machine product stoppers
Installation note:
Lubricate guide rods with ISO VG32 hydraulic oil before initial use.
For vertical installations, use auxiliary support brackets when cycle rate exceeds 120cpm.
Maintain 0.3mm minimum clearance between adjustable stoppers during stroke setting.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
