Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-50S
AirTAC SIJ200 Dual-Axis Adjustable Cylinder SIJ200X100-50S Specifications
- Model: SIJ200X100-50S
- Type: Dual-axis adjustable cylinder with guide rods
- Bore size: 200mm
- Stroke: 100mm (±50mm adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Rubber buffer + adjustable shock absorber
- Piston rod material: Hard chrome-plated carbon steel
- Mounting type: Standard base mounting (SW200 bracket included)
- Port size: PT1/2 (G1/2 optional)
- Operating temperature: -10℃ to 80℃
- Seal material: NBR + PU hybrid seals
- Weight: 15.8kg ±3%
- Dimensions: 330mm(L) × 245mm(W) × 235mm(H)
- Rod end thread: M20×1.5
- Max lateral load capacity: 1200N
- Lubrication: Pre-lubricated (Grease port for maintenance)
Heavy-duty dual-axis cylinder designed for precision alignment applications, featuring synchronized movement through twin guide rods and micrometer-style stroke adjustment (±50mm). The hardened guide shafts with bronze bushings ensure parallel movement accuracy within 0.1mm/m. Includes anti-rotation mechanism and dual shock absorption system for high-speed operations.
- Automated palletizing system position correction
- Press machine die height adjustment
- Large-format CNC router tool changers
- Solar panel assembly line positioning
- Automotive welding fixture alignment
Installation note:
Requires rigid mounting surface with flatness ≤0.2mm. For vertical installations,
use auxiliary support brackets. Lubricate guide shafts every 500km of travel
using ISO VG32 hydraulic oil. Adjust cushioning screws gradually during commissioning.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
