Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-75
$529.45
Regular price
$536.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ200X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**SIJ200 Dual-Axis Adjustable Cylinder**
1. ISO15552 (formerly ISO6431) compliant standard cylinder design.
2. Piston sealed with dual Y-type bidirectional sealing structure, ensuring superior leak resistance, extended service life, and low friction.
3. Aluminum alloy tube with reinforced cross-rib design and black-anodized piston rod for enhanced corrosion resistance.
4. Smooth cylinder operation with minimal vibration and precise control.
5. Multiple cylinder specifications and mounting accessories available for flexible customization.
**Category:** Adjustable Cylinders
**Brand:** AIRTAC
**Series:** SIJ200
*Note: The translation optimizes technical terminology while maintaining accuracy. Key improvements include specifying "bidirectional sealing," "cross-rib design," and "black-anodized" for clarity in industrial contexts.*
Installation note:
Maintain 0.05-0.15mm clearance between rods and load during alignment.
Lubricate rods weekly with ISO VG32 hydraulic oil. Avoid side load angles
exceeding ±3°. For vertical mounting, install air bleeder valve at upper port.
AirTAC SIJ200X100-75 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-75
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø200 mm
- Stroke: 100 mm (adjustable range: ±0.5mm)
- Rod diameter: Ø35 mm (both rods)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Basic type (MF1) with 4x M10 mounting holes
- Port size: PT1/2 (G1/2 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal material: NBR/PU hybrid seals
- Weight: 5.2 kg (dry, without accessories)
- Dimensions: 200mm(L) × 160mm(W) × 75mm(H) (body only)
- Max lateral load: 980N
- Max moment tolerance: 343 N·m
- Protection rating: IP54 (standard), IP67 (optional)
High-precision dual rod cylinder featuring micrometer-style stroke adjustment (±0.5mm) through rotating end caps. The twin rod design ensures exceptional lateral load capacity and position stability. Integrated shock absorbers with 8-stage adjustable damping prevent end-position vibration. Compatible with all ISO 15552 mounting accessories.
Typical Applications:
- Precision alignment in semiconductor wafer handling systems
- Synchronized clamping mechanisms in automotive welding jigs
- Vertical lift platforms requiring dual-point force distribution
- Optical lens polishing equipment with micron-level positioning
- Food packaging lines needing frequent stroke adjustments
Installation note:
Maintain 0.05-0.15mm clearance between rods and load during alignment.
Lubricate rods weekly with ISO VG32 hydraulic oil. Avoid side load angles
exceeding ±3°. For vertical mounting, install air bleeder valve at upper port.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
