Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-75S
$538.75
Regular price
$546.25
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ200X100-75S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**SIJ200 Dual-Axis Adjustable Cylinder**
1. ISO15552 (formerly ISO6431) compliant standard cylinder design.
2. Piston sealed with dual Y-type bidirectional sealing structure, ensuring superior leak resistance, extended service life, and low friction.
3. Aluminum alloy tube with reinforced cross-rib design and black-anodized piston rod for enhanced corrosion resistance.
4. Smooth cylinder operation with minimal vibration and precise control.
5. Multiple cylinder specifications and mounting accessories available for flexible customization.
**Category:** Adjustable Cylinders
**Brand:** AIRTAC
**Series:** SIJ200
*Note: The translation optimizes technical terminology while maintaining accuracy. Key improvements include specifying "bidirectional sealing," "cross-rib design," and "black-anodized" for clarity in industrial contexts.*
Installation note:
Use alignment jig (P/N: SJ-AJ200) during mounting to ensure shaft parallelism.
Lubricate with ISO VG32 hydraulic oil before initial operation. Maximum lateral
load: 15N per shaft at mid-stroke position.
Maintenance alert:
Re-torque mounting bolts to 3.5N·m after first 50 operating hours.
Avoid using silicone-based lubricants to prevent seal degradation.
AirTAC SIJ200X100-75S Twin Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-75S
- Type: Twin-axis adjustable profile cylinder
- Bore size: 20mm
- Stroke: 100mm
- Rod type: Double chrome-plated steel shafts
- Adjustment range: ±5° angular adjustment
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard), optional NPT1/8
- Mounting style: Dual front flange with 75mm center distance
- Body material: Anodized aluminum alloy
- Piston rod material: SUS304 stainless steel
- Seal material: NBR (Nitrile rubber)
- Weight: 2.3kg (with standard accessories)
- Dimensions: 200mm(L) × 100mm(W) × 75mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Accessories: Built-in cushion adjustment screws, magnetic switch slots (sensors not included)
High-precision twin-axis cylinder featuring independent angular adjustment (±5°) through eccentric collars on both shafts. Integrated shock absorption with 3-stage adjustable cushions reduces end-impact noise below 75dB. The dual-shaft design maintains parallel alignment within 0.1mm deviation under full load.
Typical Applications:
- Precision positioning in semiconductor handling robots
- Parallel gripper mechanisms for packaging lines
- Tool positioning in CNC fixture systems
- Material transfer units requiring angular compensation
- 3D printer head alignment systems
Installation note:
Use alignment jig (P/N: SJ-AJ200) during mounting to ensure shaft parallelism.
Lubricate with ISO VG32 hydraulic oil before initial operation. Maximum lateral
load: 15N per shaft at mid-stroke position.
Maintenance alert:
Re-torque mounting bolts to 3.5N·m after first 50 operating hours.
Avoid using silicone-based lubricants to prevent seal degradation.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
