Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-10
AirTAC SIJ200X1000-10 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X1000-10
- Type: Dual-rod adjustable stroke cylinder (double-axis)
- Bore size: Ø20mm
- Stroke: 1000mm (adjustable via mechanical stoppers)
- Mounting type: Front flange & rear foot mounting
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning: Adjustable air cushion at both ends
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal type: NBR rubber (oil & wear resistant)
- Weight: 6.5kg ±3% (without accessories)
- Dimensions: 1045mm(L) × 58mm(W) × 58mm(H)
- Max lateral load: 15N (at full extension)
- Repeat positioning accuracy: ±0.2mm
- ISO standard: 15552 (VDMA 24562)
High-precision dual-rod cylinder engineered for heavy-duty linear motion requiring exceptional alignment stability. Features symmetrical force distribution across parallel rods, preventing piston rotation during operation. The hardened guide rods enable precise positioning in applications with side loads. Built-in stroke adjustment allows fine-tuning between 50-1000mm using external locking nuts.
- Automated welding fixture positioning systems
- PCB board handling in SMT production lines
- Glass panel transfer mechanisms
- Automotive assembly line clamping devices
- Long-stroke press feeding equipment
Installation note:
Use alignment jigs during mounting to ensure parallel rod orientation.
For strokes >800mm, install intermediate support brackets every 300mm.
Lubricate rods weekly with ISO VG32 hydraulic oil in high-cycle applications.
Critical parameters:
Maintain air filtration at 5μm or finer.
Maximum permissible speed: 500mm/s (cushion adjustment required above 300mm/s).
Do not exceed 80% of max lateral load in vertical installations.
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
