Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-10S
AirTAC SIJ200X1000-10S Double Axis Adjustable Cylinder Specifications
- Model: SIJ200X1000-10S
- Type: Double rod adjustable stroke cylinder (ISO 15552 standard)
- Bore size: Ø200 mm
- Stroke: 1000 mm (adjustable through stopper mechanism)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Mounting type: Basic fixed (MF1) with optional foot mounting
- Rod diameter: Ø40 mm (chrome-plated steel)
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Non-relubrication design)
- Weight: 38.5 kg (including rods and end caps)
- Dimensions:
- Body length: 1230 mm (stroke 1000 + basic length 230)
- Overall width: 280 mm (including guide rods)
- Height: 240 mm (from base to rod centerline)
- Port size: G1/2 (BSPP thread)
- Material: Aluminum alloy body, hardened steel guide rods
- Protection class: IP65 (standard wiper seal)
Heavy-duty dual-axis cylinder engineered for precision linear motion control in high-load applications. Features synchronized guide rods for enhanced moment resistance and anti-rotation stability. The hydraulic cushioning system allows smooth deceleration at stroke ends, while the through-rod design enables external position feedback device installation.
- Automotive production line clamping fixtures
- Press machine ejection systems
- Large-format CNC router Z-axis drives
- Steel coil handling equipment
- Injection molding machine core pull mechanisms
Installation recommendation:
Ensure parallel alignment of guide rods within 0.2mm/m tolerance.
Use locknuts (included) for stroke adjustment. Lubricate guide rods weekly
with ISO VG32 hydraulic oil in high-cycle applications (>500 cycles/hour).
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
