Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-20
AirTAC SIJ200X1000-20 Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ200X1000-20
- Type: Dual-axis adjustable ISO standard cylinder
- Bore size: Ø200 mm
- Stroke: 1000 mm (adjustable through external stoppers)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (cushioned)
- Ambient temperature: -20℃ to 80℃
- Mounting type: FA series flange base (adjustable rail mounting)
- Rod end type: Female threaded (M45×2)
- Cushioning: Adjustable air cushion with shock absorber
- Port size: G1/2 (standard), optional NPT1/2
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal type: NBR seals with wear-resistant ring
- Weight: 32.5 kg (dry, without accessories)
- Dimensions: 1340mm(L) × 240mm(W) × 260mm(H) (max extended length)
Heavy-duty dual-axis cylinder engineered for precision positioning in industrial automation. Features twin piston rods for enhanced moment resistance and anti-rotation stability. The 20mm adjustable rail system allows ±10° angle compensation during installation. Includes built-in magnet for sensor mounting and triple sealing system for harsh environments.
- Automotive welding fixture positioning systems
- Large-format CNC machine tool clamping
- Sheet metal press brake back gauge systems
- Heavy load transfer in assembly lines
- Glass panel handling robotics
Installation note:
Requires parallel alignment within 0.2mm/m using alignment gauge.
Lubricate piston rod weekly with ISO VG32 hydraulic oil in high-cycle applications.
Maximum side load capacity: 850N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
