Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-20S
AirTAC SIJ200X1000-20S Double Rod Adjustable Cylinder Specifications
- Full model: SIJ200X1000-20S
- Type: Double rod adjustable stroke cylinder (ISO 6432 compliant)
- Bore size: Ø20 mm
- Stroke length: 1000 mm (adjustable through stopper mechanism)
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: Ø10 mm (dual rods)
- Cushioning: Adjustable rubber buffer on both ends
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Ambient temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
- Mounting type: Basic (no built-in mounts)
- Material: Aluminum alloy barrel, hardened steel rods
- Weight: 3.8 kg ±2% (without accessories)
- Dimensions:
- Length: 1400 mm (full extension)
- Body width: 40 mm
- Height: 60 mm (including rod ends)
High-precision dual rod cylinder designed for applications requiring rigid alignment and adjustable positioning. Features symmetrical force distribution through parallel rods and wear-resistant chromium-plated piston rods. Requires clean compressed air with 5-50μm filtration. Optional magnetic piston version (add "-M" suffix) available for position sensing.
- Precision glass cutting machinery
- Semiconductor wafer handling systems
- Automated textile tensioning devices
- 3D printer gantry stabilization
- Pharmaceutical packaging alignment
Installation guidelines:
Maximum side load ≤15% of thrust capacity. For full stroke applications,
reduce operating pressure to 0.7MPa. Lubricate rod surfaces monthly in
high-cycle operations (>500 cycles/hour).
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
