Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-30
AirTAC SIJ200X1000-30 Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ200X1000-30
- Type: Dual-axis adjustable stroke cylinder (ISO 15552 standard)
- Bore size: 200 mm
- Stroke: 1000 mm (adjustable via mechanical stoppers)
- Mounting type: Front flange & rear foot mounting (NF series compatible)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable air cushion at both ends
- Operating temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy with hard anodized surface
- Piston rod: Chrome-plated steel (Cr-Mo)
- Seals: NBR (Nitrile) standard, optional FKM/Viton
- Port size: G1/2 (BSPP thread)
- Rod diameter: 40 mm
- Repeat accuracy: ±0.5 mm
- Weight: 38.6 kg (with standard components)
- Dimensions (L×W×H):
- Extended length: 1340 mm
- Retracted length: 340 mm
- Body width: 240 mm
- Mounting height: 300 mm
Heavy-duty dual-axis cylinder engineered for precision linear motion control in industrial automation. Features synchronized dual piston rods for enhanced moment resistance and parallel movement accuracy. The adjustable stroke mechanism allows ±5% stroke modification through external limit screws. Corrosion-resistant construction with IP67 protection rating ensures reliable operation in harsh environments.
- Automotive welding fixture positioning systems
- Large-format CNC machine tool clamping devices
- Palletizing robot end-effector guidance
- Steel coil handling equipment
- Plastic injection molding machine ejectors
Installation guidelines:
Use alignment jigs during mounting to ensure parallel rod movement.
Lubricate with ISO VG32 hydraulic oil during initial setup.
Maintain 0.3-0.6 MPa operating pressure for optimal cushioning performance.
Allow 50mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
