Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-30S
AirTAC SIJ200 Dual-Axis Adjustable Cylinder SIJ200X1000-30S Specifications
- Model: SIJ200X1000-30S
- Type: Dual-axis adjustable stroke cylinder (mechanical lock type)
- Bore size: 200mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable air cushion at both ends
- Mounting: Standard foot mounting (ISO 15552 compatible)
- Port size: G3/8 (M14×1.5 optional)
- Piston rod thread: M30×1.5
- Material: Anodized aluminum alloy cylinder tube, hard chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54 (standard wipers)
- Weight: 18.7kg (excluding accessories)
- Dimensions:
- Length: 1400mm (full extension)
- Body width: 220mm (mounting base included)
- Height: 240mm (including piston rod)
High-precision dual-axis cylinder with mechanical stroke adjustment lock, designed for heavy-duty applications requiring precise linear motion control. Features corrosion-resistant construction with double guide rods for enhanced stability under lateral loads. Includes magnetic piston for position sensing compatibility (sensor not included). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- Automated material handling systems
- Press machine ejection mechanisms
- Automotive assembly line positioning
- Large-format CNC machine tool clamping
- Packaging line product alignment systems
Installation note:
Ensure proper alignment of dual guide rods using alignment jigs during installation.
Recommended lubrication interval: 500km travel distance or 6 months.
Maximum side load capacity: 850N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
