Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-50
$1,194.79
Regular price
$1,202.29
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ200X1000-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**SIJ200 Dual-Axis Adjustable Cylinder**
1. ISO15552 (formerly ISO6431) compliant standard cylinder design.
2. Piston sealed with dual Y-type bidirectional sealing structure, ensuring superior leak resistance, extended service life, and low friction.
3. Aluminum alloy tube with reinforced cross-rib design and black-anodized piston rod for enhanced corrosion resistance.
4. Smooth cylinder operation with minimal vibration and precise control.
5. Multiple cylinder specifications and mounting accessories available for flexible customization.
**Category:** Adjustable Cylinders
**Brand:** AIRTAC
**Series:** SIJ200
*Note: The translation optimizes technical terminology while maintaining accuracy. Key improvements include specifying "bidirectional sealing," "cross-rib design," and "black-anodized" for clarity in industrial contexts.*
Installation guidelines:
Must maintain ≤0.1mm/m parallelism between rods. Use alignment jigs during mounting.
For strokes >800mm, install intermediate rod supports every 400mm. Lubricate guide shafts
with ISO VG32 hydraulic oil monthly under normal operation.
AirTAC SIJ200 Dual Axis Adjustable Cylinder SIJ200X1000-50 Technical Specifications
- Model: SIJ200X1000-50
- Type: Double rod adjustable stroke cylinder (ISO 15552 compliant)
- Bore size: Ø200 mm
- Stroke: 1000 mm (adjustable through built-in stroke limiter)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Basic type (optional fixed or flange mounts)
- Weight: 28.5 kg (±2%)
- Dimensions:
- Length: 1485 mm (full extension)
- Body width: 240 mm (including rod supports)
- Height: 220 mm (from base to rod centerline)
- Material:
- Cylinder tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated carbon steel (Cr-Mo)
- Seals: NBR+PU hybrid for high-speed applications
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (recommended relubrication every 500km stroke)
Heavy-duty dual rod cylinder designed for precision alignment in long-stroke applications. Features synchronized movement through parallel piston rods with adjustable stroke limiter (mechanical lock type). Integrated shock absorbers minimize end-impact vibration in high-cycle operations. Requires 5μm filtered air with <0.5mg/m³ oil content.
Industrial Applications:
- Automotive production line fixture positioning
- Large-format CNC router tool changers
- Paper converting machinery web tension control
- Glass panel handling systems
- Wind turbine blade mold adjustment mechanisms
Installation guidelines:
Must maintain ≤0.1mm/m parallelism between rods. Use alignment jigs during mounting.
For strokes >800mm, install intermediate rod supports every 400mm. Lubricate guide shafts
with ISO VG32 hydraulic oil monthly under normal operation.
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
