Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-50S
AirTAC SIJ200X1000-50S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X1000-50S
- Type: Dual rod compact cylinder with adjustable stroke
- Bore diameter: Ø200mm
- Stroke length: 1000mm (customizable up to 1500mm)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–1000 mm/s (with cushioning)
- Ambient temperature: -10℃ to 80℃
- Cushioning type: Adjustable rubber bumper (both ends)
- Port size: G3/8 (NPT1/2 optional)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy (anodized finish)
- Seal material: NBR/PU combination
- Weight: ~78kg (with standard mounting brackets)
- Dimensions: 1490mm(L) × 240mm(W) × 240mm(H)
- Mounting options: MF1/MF2 flange, MY3 series compatible
- Protection rating: IP54 (standard), IP67 (optional wiper upgrade)
Heavy-duty dual rod cylinder engineered for precision linear motion in high-moment applications. Features twin chrome-plated guide rods (Ø50mm) with anti-rotation design, providing exceptional lateral load capacity (up to 18kN). Integrated stroke adjustment mechanism allows ±5mm fine-tuning via lock nuts. Pre-lubricated for maintenance-free operation.
- Automotive welding fixture positioning systems
- Press machine ejection mechanisms
- Large-format CNC router Z-axis control
- Glass handling vacuum lifters
- Palletizing robot end-effector alignment
Installation guidelines:
Requires rigid mounting surface (flatness ≤0.1mm/m). Maintain 0.5mm minimum clearance between rods and adjacent components.
For full stroke operation, use 5-7 bar filtered air with 20-30μm particulate filtration. Lubricate through port weekly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
