Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-75
AirTAC SIJ200X1000-75 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X1000-75
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø200 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Dual rod diameter: Ø25 mm each
- Stroke adjustment: Mechanical stopper with locknut
- Mounting style: MF1 flange with reinforced base
- Port size: G1/2 (BSPP thread)
- Cushioning: Adjustable air cushion at both ends
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR + polyurethane hybrid seals
- Weight: 38.5 kg ±2%
- Dimensions (L×W×H): 1430mm × 260mm × 260mm (full extension)
Heavy-duty dual rod cylinder with precision stroke adjustment capability, featuring twin piston rods for enhanced moment resistance and position stability. The hardened chrome piston rods (HRC 45-50) withstand side loads up to 750N. Includes wear-resistant guide bushings and IP67-rated dust wipers. Requires 40μm filtered lubricated air (ISO 8573-1:2010 Class 4.4.3).
- Automated palletizing systems requiring variable stroke control
- Large-format CNC material handling gates
- Automotive assembly line positioning fixtures
- Steel coil feeding mechanisms
- Paper mill roller adjustment systems
Installation note:
Ensure proper alignment using alignment pins (2-Ø12H7 holes provided).
Lubricate through integrated grease nipple (NLGI #2) every 500km of travel.
Max allowable misalignment: 0.2mm/m. Support mid-span for strokes >800mm.
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
