Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X1000-75S
AirTAC SIJ200X1000-75S Twin Axis Adjustable Cylinder Specifications
- Model: SIJ200X1000-75S
- Type: Twin-axis adjustable stroke air cylinder
- Bore size: Ø200 mm
- Stroke length: 1000 mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable pneumatic cushion
- Mounting style: Fixed side-mount (75S series)
- Port size: G1/2 (standard), optional NPT1/2
- Operating temperature: -10℃ to 80℃
- Barrel material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated stainless steel (Cr-Mo)
- Weight: ~24.5 kg (without accessories)
- Dimensions: 1300mm(L) × 200mm(W) × 200mm(H)
- Rod diameter: Ø45 mm
- Maximum thrust: 7065N (at 0.63MPa)
- Seal material: Polyurethane (NBR optional)
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty twin-axis cylinder with precision stroke adjustment, featuring dual-piston rod stabilization for anti-rotation performance. Integrated shock absorption system with 30° adjustable cushioning angles. Corrosion-resistant construction with 20μm hard chrome plating on piston rods. Includes magnetic switch slots (sensor-ready) and dust-resistant wiper rings.
- Large-scale automated material handling systems
- Automotive assembly line positioning devices
- Heavy press machine ejection mechanisms
- Packaging line palletizing robots
- Plastic injection molding machine core-pull units
Installation notes:
Requires rigid mounting surface with flatness ≤0.1mm/m.
Lubricate with ISO VG32 hydraulic oil during initial setup.
Allow 50mm clearance for stroke adjustment access.
Use M12x1.25 mounting bolts (Grade 8.8 or higher).
| Property | Property Value |
|---|---|
| sku | SIJ200X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
