Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X120-100S
AirTAC SIJ200X120-100S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X120-100S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø200 mm
- Stroke: 120 mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Dual trunnion brackets (standard)
- Port size: G3/8 (ISO standard)
- Material: Aluminum alloy body, NBR seals
- Temperature range: -20℃ to 80℃
- Weight: 12.8 kg ±2%
- Dimensions: 430mm(L) × 240mm(W) × 240mm(H)
- Rod diameter: Ø35mm (hard chrome-plated)
- Maximum lateral load: 1500N
- Repeat positioning accuracy: ±0.5mm
- ISO certification: 6431, 15552
Heavy-duty dual-axis cylinder with mechanical locking mechanism for stroke adjustment. Features double piston rods for enhanced rigidity and anti-rotation stability. Includes wear-resistant guide bushings and IP67-rated dust protection. Requires 5-50μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- Precision material handling systems
- Automotive welding fixture positioning
- Glass panel lifting/pressing machinery
- Die-casting mold core pulling mechanisms
- Heavy conveyor gate actuators
Installation note:
Always lock adjustment screws with 18N·m torque after stroke setting.
Maintain 0.5mm minimum clearance between rod ends and adjacent components.
Lubricate guide shafts monthly under continuous operation.
| Property | Property Value |
|---|---|
| sku | SIJ200X120-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 120mm |
