Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X120-50
AirTAC SIJ200 Dual Axis Adjustable Cylinder SIJ200X120-50 Technical Details
- Model: SIJ200X120-50
- Bore size: Ø20mm
- Stroke: 120mm (adjustable)
- Rod diameter: Ø10mm x 2 (dual shafts)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–1000 mm/s
- Cushioning: Adjustable rubber buffer
- Mounting type: Front flange with 4x M5 threaded holes
- Port size: M5x0.8 (G1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal type: NBR + PU combination
- Weight: 2.3 kg (without accessories)
- Dimensions: 300mm(L) × 48mm(W) × 56mm(H) (full extension)
- Rod end thread: M10x1.25 (both shafts)
- Repeat positioning accuracy: ±0.5mm
- ISO standard: 15552 compliant
High-precision dual shaft cylinder featuring synchronized dual piston rods with anti-rotation stability. The adjustable stroke mechanism (via external locking nuts) enables micro-positioning adjustments during operation. Enhanced side load capacity through reinforced guide structure, with IP54-rated protection against particulate ingress.
- Precision alignment in semiconductor wafer handling systems
- Simultaneous clamping in CNC fixture plates
- Vertical Z-axis positioning in 3D printing/pick-and-place machines
- Parallel actuation in automotive welding jigs
- Packaging line product orientation adjustment stations
Installation guidelines:
Lubricate piston rods with ISO VG32 hydraulic oil before initial use.
Maintain minimum 0.5mm clearance between shafts and adjacent components.
For vertical mounting, install air vent valve at upper port.
Max lateral load: 150N per shaft.
| Property | Property Value |
|---|---|
| sku | SIJ200X120-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 120mm |
