Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X125-10
AirTAC SIJ200X125-10 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X125-10
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø200mm
- Stroke: 125mm (Standard, adjustable)
- Max stroke adjustment range: ±5mm
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Air cushion + external shock absorber
- Mounting style: Basic type (MF1)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Port size: G1/2
- Weight: 18.5kg ±2%
- Dimensions (L×W×H):
- Extended length: 780mm
- Retracted length: 655mm
- Body width: 240mm
- Mounting height: 300mm
Heavy-duty dual rod cylinder with micrometer-style stroke adjustment (±5mm) through rotating end caps. Features twin piston rods for enhanced moment resistance and position stability. Integrated shock absorption system combines air cushioning with mechanical buffers for high-speed operations. Mirror-finished rods with multi-layer sealing ensure ≤0.5mm/m leakage rate.
- Press machine tooling position fine-tuning
- Automotive welding fixture height adjustment
- Die-casting mold clamping force control
- Paper converting equipment tension balancing
- Palletizing robot end effector alignment
Installation protocol:
Requires torque-controlled mounting (35-40N·m for M12 mounting bolts).
Lubricate rod bearings with ISO VG32 hydraulic oil before initial operation.
Allow 50mm clearance behind end caps for stroke adjustment tools.
| Property | Property Value |
|---|---|
| sku | SIJ200X125-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 125mm |
