Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-75
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X100-75 Double Rod Adjustable Cylinder Specifications
- Model: SIJ32X100-75
- Bore size: 32mm
- Stroke: 100mm (adjustable)
- Rod diameter: 12mm (dual rods)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Piston speed: 50-700mm/s
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting type: Universal mounting (front flange, side mount, foot mount compatible)
- Port size: M5x0.8 (standard) with G1/8 adaptor optional
- Weight: 2.85kg ±3%
- Dimensions:
- Length: 232mm (full extension)
- Width: 60mm (including mounting brackets)
- Height: 75mm (cylinder body diameter)
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel
- Seals: NBR + PU combination
Precision double-rod cylinder with built-in position locking mechanism, featuring symmetrical force output and excellent lateral load capacity. The dual rod design minimizes rotation during operation while maintaining alignment accuracy. Includes external stroke adjustment screws (±3mm fine-tuning range) and anti-rotation guide slots.
- Precision positioning in semiconductor handling equipment
- Parallel gripper mechanisms in robotic assembly lines
- Vertical lifting systems with counterbalance requirements
- Packaging machine clamping units needing synchronized movement
- Automated test equipment requiring anti-rotation stability
Installation note:
For optimal performance, maintain 0.5-1mm clearance between rods during parallel installations.
Lubricate with ISO VG32 hydraulic oil before initial use. Maximum side load: 150N at mid-stroke.
- Standard: 5,000km travel distance (clean air)
- With air filter (5μm): 8,000km+
- Re-lubrication interval: Every 2 million cycles
| Property | Property Value |
|---|---|
| sku | SIJ32X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
