Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-100
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X1000-100 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ32X1000-100
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø32 mm (±0.1mm tolerance)
- Stroke: 1000 mm (max adjustable range 50-1000mm)
- Rod diameter: Ø12 mm chromium-plated steel
- Operating pressure: 0.1-1.0 MPa
- Cushioning: Adjustable rubber buffer (10mm stroke adjustment)
- Port size: G1/8 (NPT1/8 optional)
- Temperature range: -20℃ to 80℃
- Tube material: Aluminum alloy (anodized surface)
- Seal material: NBR + PU hybrid seals
- Weight: 5.8 kg (excluding mounting accessories)
- Dimensions: 1160mm(L) × 48mm(W) × 48mm(H)
- Mounting: Front flange MF12 & rear pivot mount (accessories included)
- Protection rating: IP54 (standard wiper design)
High-precision dual rod cylinder with mechanical stroke adjustment mechanism, featuring synchronized movement through twin piston rods. The chrome-hardened rods and wear-resistant seals enable 5,000km service life under rated conditions. Includes dual magnetic sensors slots (non-inductive models available).
- Precision grinding machine worktable positioning
- Automated welding equipment cross-axis control
- LCD panel handling systems requiring parallel motion
- Packaging line product height adjustment stations
- Automotive wheel alignment testing rigs
Installation note:
Maintain 0.5mm minimum clearance between rods during parallel installation.
Lubricate with ISO VG32 hydraulic oil before initial operation. Avoid side
loads exceeding 30N. Stroke adjustment requires simultaneous tightening of
both lock nuts (15N·m torque recommended).
| Property | Property Value |
|---|---|
| sku | SIJ32X1000-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <1000mm> |
