Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X120-50S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X120-50S Double Rod Adjustable Cylinder Specifications
- Model: SIJ32X120-50S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø32mm
- Stroke: 120mm (adjustable)
- Operating pressure: 0.1~0.9 MPa
- Medium temperature: -20℃ to 80℃
- Material: Aluminum alloy body, hard anodized rods
- Seal material: NBR (Nitrile rubber)
- Cushioning: Adjustable elastic cushion at both ends
- Port size: M5x0.8 (standard), G1/8 optional
- Rod diameter: Ø16mm (both rods)
- Stroke adjustment range: 0-120mm continuous adjustment
- Repeat positioning accuracy: ±0.2mm
- Weight: 2.2kg (without accessories)
- Dimensions: 220mm(L) × 50mm(W) × 60mm(H) (at full extension)
- Mounting: Square front flange (ISO 15552 standard)
- Protection rating: IP40 (dust protected)
Precision double rod cylinder featuring dual-axis stabilization for enhanced moment resistance. The through-rod design ensures symmetrical force distribution, while the stroke adjustment mechanism allows micrometer-level positioning via hex wrench. Includes anti-rotation guide slots and wear-resistant rod surfaces with chrome plating (2-3μm thickness). Requires ISO VG32 grade lubricant for optimal performance.
- Precision fixturing in CNC machining centers
- Vertical lift mechanisms in semiconductor handling
- Parallel gripper configurations in packaging lines
- Positioning stages for optical inspection systems
- Clamping devices in plastic injection molding
Installation notes:1. Maintain 0.5mm minimum clearance between rods during alignment
2. Use torque-controlled mounting (8-10Nm for M6 screws)
3. For stroke adjustment: Loosen lock nut, turn adjustment screw (1 full rotation = 1.5mm stroke change)
4. Recommended air filtration: 5μm with auto-drain
| Property | Property Value |
|---|---|
| sku | SIJ32X120-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
