Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X125-10
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X125-10 Double Rod Adjustable Cylinder Specifications
- Model: SIJ32X125-10
- Type: Double rod adjustable stroke cylinder (ISO 6432 compliant)
- Bore size: 32mm (±0.1mm manufacturing tolerance)
- Stroke: 125mm (adjustable in 1mm increments)
- Rod diameter: 16mm (hard chrome-plated)
- Operating pressure: 0.1–0.8 MPa (1–8 bar)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting: Side-mounted with 4x M6 threaded holes (32mm center spacing)
- Port size: PT1/8 (G1/8 adaptor included)
- Material: Aluminum alloy body (anodized), Stainless steel tie rods
- Seal type: NBR (nitrile) with wear-resistant ring
- Weight: 2.3kg (excluding accessories)
- Dimensions: 225mm(L) × 70mm(W) × 60mm(H) (at full extension)
- Rod end type: 5mm female thread (M5×0.8)
- Max piston speed: 500mm/s (with cushion engaged)
- Lubrication: Pre-lubricated (use ISO VG32 pneumatic oil if required)
Precision double-rod cylinder featuring micrometer-style stroke adjustment (10mm minimum stroke reduction) through rotating end caps. The dual rod design eliminates piston rotation, making it ideal for applications requiring parallel motion. Includes built-in magnetic sensor groove (4mm width) for position feedback devices.
- Precision clamping fixtures in CNC machining centers
- Vertical lift mechanisms in packaging lines
- Web tensioning systems in printing machinery
- Wafer handling robots in semiconductor FABs
- Synchronized gate actuators in automotive assembly
Installation note:
Align both rods within 0.05mm parallel tolerance using alignment jigs.
For stroke adjustment: 1 full rotation = 2mm stroke reduction (clockwise).
Apply anti-seize compound on adjustment threads for maintenance.
| Property | Property Value |
|---|---|
| sku | SIJ32X125-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
