Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X125-100
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X125-100 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ32X125-100
- Type: Double rod, adjustable stroke cylinder
- Bore size: Ø32mm
- Full stroke: 125mm
- Adjustable stroke range: 25-100mm (mechanical stopper)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports on both ends)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front flange/Foot mounting (optional accessories)
- Rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 2.1kg ±5% (with standard fittings)
- Dimensions (L×W×H):
- Body length: 260mm (at full extension)
- Cross section: 32mm × 50mm (W×H)
- Mounting base: 45mm × 55mm
Precision dual-axis cylinder featuring micrometer-style stroke adjustment with locknut mechanism. The symmetrical rod design minimizes lateral deflection during operation, with integrated cushioning adjustment screws for smooth end-of-stroke deceleration. Includes wear-resistant guide bushings and IP67-rated wiper seals for contaminated environments.
- Precision positioning in robotic pick-and-place systems
- Clamping fixtures for CNC machining centers
- Material handling gates in packaging lines
- Z-axis adjustment in semiconductor wafer handling
- Tool height adjustment in automated assembly stations
Installation tip:
Use alignment jigs during mounting to ensure parallel rod movement.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maximum side load capacity: 15N at mid-stroke position.
| Property | Property Value |
|---|---|
| sku | SIJ32X125-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
