Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X125-100S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X125-100S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ32X125-100S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø32mm
- Stroke: 125mm
- Adjustment range: 0-100mm (stroke reduction via external stopper)
- Operating pressure: 0.1-0.9 MPa
- Piston rod diameter: Ø12mm (both rods)
- Mounting style: Front flange (MF1) / Side lug (MP2) optional
- Cushioning: Rubber buffer + adjustable cushion screw
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Weight: 2.8kg (excluding accessories)
- Dimensions: 320mm(L) × 76mm(W) × 76mm(H)
- Port size: Rc1/8 (G1/8 optional)
- Protection rating: IP54 (standard wiper design)
- Max thrust: 226N @0.5MPa
High-rigidity dual rod cylinder with mechanical stroke adjustment mechanism, featuring synchronized piston movement for precision positioning. The hardened chrome-plated rods and aluminum alloy body ensure durability in high-cycle applications. Includes dual cushioning system with adjustable deceleration and magnetic piston for sensor compatibility.
- Precision fixturing in CNC machine tool changers
- Parallel gripper actuation in robotic assembly lines
- Vertical lifting mechanisms in packaging machinery
- Position adjustment in semiconductor wafer handling
- Press-fit operations in automotive component assembly
Installation note:
Ensure proper alignment of dual rods using alignment jigs during mounting.
For stroke adjustment: Loosen lock nut, rotate stopper (1 rotation = 5mm stroke change),
then retighten with 2.5N·m torque. Lubricate with ISO VG32 hydraulic oil before initial use.
- Inspect rod seals every 500,000 cycles
- Re-lubricate every 3 months or 200 operating hours
- Max permissible rod end play: ±0.5mm
| Property | Property Value |
|---|---|
| sku | SIJ32X125-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
