Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X100-100
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X100-100 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ40X100-100
- Bore size: 40mm
- Stroke: 100mm (adjustable at both ends)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer
- Mounting type: Standard foot/base mount (optional flange)
- Port size: M5x0.8 (G1/8 adaptor included)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy anodized finish
- Seal type: NBR wear-resistant seals
- Weight: 2.45 kg ±3%
- Dimensions (L×W×H): 280mm × 78mm × 58mm
- Repeat positioning accuracy: ±0.2mm
- Max lateral load: 50N
- ISO certification: 6431, 15552 compliant
High-precision dual-axis cylinder featuring micrometer-style stroke adjustment (±5mm fine-tuning range) with lock nuts. The hardened guide rods and precision linear bushings ensure smooth operation under side loads. Includes anti-rotation design for stable vertical/horizontal mounting. Requires lubrication-free operation with ISO 8573-1:2010 [3:4:3] class air quality.
- PCB handling robots with position-sensitive grippers
- Glass panel polishing equipment Z-axis control
- Automated screw driving machines with depth adjustment
- Pharmaceutical blister packaging alignment systems
- Semiconductor wafer transfer mechanisms
Installation protocol:
Align guide rods within 0.1mm/m parallelism tolerance. Use flexible couplings
when connecting to driven components. Apply thread locker (medium strength)
after final position calibration. Maintenance cycle: 2,000km travel distance
or 12 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | SIJ40X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
