Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X100-20
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X100-20 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ40X100-20
- Type: Double rod adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 100mm (adjustable range: ±5mm)
- Rod type: Double chrome-plated steel rods
- Adjustment mechanism: Hexagonal lock nut with graduated scale
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Rubber buffer + adjustable shock absorber
- Mounting: Standard ISO 15552 front flange
- Port size: G1/8 (NPT1/8 optional)
- Seal material: Polyurethane (NBR available on request)
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500mm/s
- Weight: 1.8kg (excluding accessories)
- Dimensions: 178mm(L) × 80mm(W) × 40mm(H)
Precision dual-axis cylinder with mechanical stroke adjustment, featuring twin hardened steel rods for enhanced stability in lateral load applications. The dual-cushion design minimizes end-stop vibration, while the laser-etched scale enables micron-level positioning adjustments. Includes built-in magnetic sensor slots (M5x0.8 threaded) for position feedback integration.
- Precision fixturing in CNC machine tool changers
- Variable stroke press brake tooling systems
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing mechanisms
- Automated optical inspection positioning stages
Operation note:
Lubricate rods weekly with ISO VG32 hydraulic oil. When adjusting stroke under pressure,
release air pressure first to prevent thread galling. Maximum side load capacity: 35N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SIJ40X100-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
