Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X100-30
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X100-30 Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ40X100-30
- Type: Dual-axis adjustable cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 100mm (adjustable in 1mm increments)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 70℃
- Cushioning type: Rubber cushioning at both ends
- Mounting style: Front flange & side hole mounting
- Port size: M5x0.8 (standard), G1/8 optional
- Rod type: Double chrome-plated stainless steel
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 2.8kg ±3%
- Dimensions (L×W×H): 220mm × 48mm × 48mm (body), 50mm × 50mm × 25mm (mounting block)
- Repeat positioning accuracy: ±0.2mm
- Max lateral load: 180N
- Protection rating: IP40 (dust protected)
High-precision dual-axis cylinder featuring a unique mechanical locking mechanism for position retention. The hardened guide rods and precision ball bushings ensure smooth linear motion with minimal deflection. Includes adjustable stroke limiters with 1mm graduation marks and 3-position mounting slots for flexible installation. Compatible with ISO 15552 mounting accessories.
- Precision alignment in semiconductor wafer handling
- Vertical lifting mechanisms for CNC tool changers
- Dual-axis positioning in automated inspection stations
- Clamping fixtures for robotic welding systems
- Material transfer gates in packaging lines
Installation note:
Always align guide rods parallel within 0.1mm/m tolerance. Apply lithium-based grease to ball bushings
during maintenance. Use locknuts with 1.5Nm torque for stroke adjusters. Avoid side impact loads exceeding
50N during operation.
| Property | Property Value |
|---|---|
| sku | SIJ40X100-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
