Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X100-30S
$73.27
Regular price
$80.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ40X100-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (formerly ISO 6431) standard double rod adjustable cylinder.
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
Installation note:
Ensure both rods move freely without binding. Use locknuts (included) for stroke adjustment fixation.
Lubricate through air port using ISO VG32 hydraulic oil mist (0.5-1.0 cc/m³) for optimal performance.
Max lateral load: 50N at rod end.
For eccentric loads exceeding 25N, install linear guides parallel to cylinder axis.
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X100-30S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ40X100-30S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø40mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05-0.9 MPa
- Medium temperature: -20℃ to 80℃
- Port size: Rc1/8 (G1/8 optional)
- Piston speed: 50-700 mm/s
- Mounting type: Standard (SW40x40mm square base)
- Rod end type: External M10x1.25 thread
- Buffer type: Adjustable rubber cushion
- Seal material: Polyurethane (NBR optional)
- Weight: 2.85 kg (±3%)
- Dimensions (L×W×H):
- Extended length: 280mm
- Retracted length: 180mm
- Body width: 58mm
- Mounting base: 40×40mm
- Rod center height: 20mm
Precision dual-axis cylinder with mechanical stroke adjustment mechanism, featuring symmetrical force transmission and enhanced lateral load capacity. The hardened chrome-plated piston rod and aluminum alloy body ensure durability in high-cycle applications. Includes dual magnetic sensor slots (T-slot and U-slot) for flexible position detection.
Typical Applications:
- Precision clamping fixtures in CNC machining centers
- Vertical Z-axis positioning in automated assembly lines
- Parallel gripper mechanisms for robotic arms
- Material handling systems requiring dual-point force application
- Optical equipment alignment stages
Installation note:
Ensure both rods move freely without binding. Use locknuts (included) for stroke adjustment fixation.
Lubricate through air port using ISO VG32 hydraulic oil mist (0.5-1.0 cc/m³) for optimal performance.
Max lateral load: 50N at rod end.
For eccentric loads exceeding 25N, install linear guides parallel to cylinder axis.
| Property | Property Value |
|---|---|
| sku | SIJ40X100-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
