Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X100-50SN
$73.27
Regular price
$80.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ40X100-50SN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (formerly ISO 6431) standard double rod adjustable cylinder.
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
Installation note:
Maintain 0.5mm minimum clearance between rods during parallel installations.
For vertical mounting, use auxiliary guide mechanisms when payload exceeds 15kg.
Lubricate rods monthly with ISO VG32 hydraulic oil in high-cycle applications.
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X100-50SN Dual Axis Adjustable Cylinder Specifications
- Model: SIJ40X100-50SN
- Type: Double rod, adjustable stroke pneumatic cylinder
- Bore size: 40mm
- Stroke: 100mm (adjustable ±5mm via external stoppers)
- Rod diameter: 12mm (both rods)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Port size: Rc1/8 (NPT1/8 optional)
- Cushioning: Adjustable air cushion at both ends
- Mounting type: Standard foot/base mount (ISO 15552 compatible)
- Material: Aluminum barrel, chrome-plated steel rods
- Seal type: NBR seals with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Weight: 1.8kg (without accessories)
- Dimensions: 200mm(L) × 80mm(W) × 48mm(H) (at mid-stroke)
- Sensor compatibility: Supports S-04-2N magnetic switches
- Lubrication: Pre-lubricated (optional oil-free operation)
A precision dual-rod cylinder with anti-rotation stability, featuring dual-axis guidance for enhanced moment resistance. The chrome-plated rods and double lip seals ensure smooth operation in high-side-load applications. The stroke adjustment mechanism allows ±5mm fine-tuning through hex wrench-operated mechanical stoppers.
Typical Applications:
- Precision alignment in PCB handling robots
- Vertical lifting mechanisms in packaging lines
- Clamping fixtures for CNC machine tooling
- Position-stable material transfer units
- Automated optical inspection (AOI) positioning stages
Installation note:
Maintain 0.5mm minimum clearance between rods during parallel installations.
For vertical mounting, use auxiliary guide mechanisms when payload exceeds 15kg.
Lubricate rods monthly with ISO VG32 hydraulic oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SIJ40X100-50SN |
| Adjustable Stroke | <50mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
