Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X125-20
$73.01
Regular price
$80.51
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ40X125-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (formerly ISO 6431) standard double rod adjustable cylinder.
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
Installation recommendations:
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X125-20 Twin Shaft Adjustable Cylinder Specifications
- Model: SIJ40X125-20
- Type: Twin shaft double-acting cylinder with adjustable cushioning
- Bore size: 40mm
- Stroke: 125mm (±0.5mm tolerance)
- Rod diameter: 16mm (both shafts)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: G1/8 (NPT1/8 optional)
- Cushion type: Adjustable rubber bumper (both ends)
- Mounting style: Standard (no base bracket included)
- Material: Aluminum alloy body, hard chrome-plated piston rods
- Seal material: NBR/PU hybrid seals
- Weight: 2.45kg ±3%
- Dimensions:
- Total length (L): 249mm (cylinder body) + 2×25mm (rod extension) = 299mm
- Width (W): 62mm (including mounting bosses)
- Height (H): 62mm (shaft center to mounting surface)
- ISO standard: 15552 (formerly ISO 6431)
- Protection rating: IP54 (standard), IP67 optional
High-precision twin shaft cylinder with enhanced lateral load capacity and position stability. Features dual-axis guidance for applications requiring anti-rotation and precise linear motion. The symmetrical design reduces deflection during operation, making it ideal for pick-and-place systems requiring millimeter-level repeatability.
Typical Applications:
- Semiconductor wafer handling robots
- Precision press tool alignment systems
- Automated optical inspection (AOI) equipment
- Glass panel transfer mechanisms
- Pharmaceutical blister packaging machines
Installation recommendations:
- Align shafts within 0.2mm parallel tolerance to prevent binding
- Use rigid mounting surface with flatness ≤0.1mm/m
- For vertical installations, add mechanical brake on at least one shaft
- Lubricate rods monthly with ISO VG32 hydraulic oil (non-detergent)
| Property | Property Value |
|---|---|
| sku | SIJ40X125-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 125mm |
