Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X125-40
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X125-40 Double Rod Adjustable Cylinder Specifications
- Model: SIJ40X125-40
- Type: Double rod adjustable stroke pneumatic cylinder
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm adjustment range)
- Rod diameter: 12mm (both rods)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (M5 optional)
- Mounting type: 40mm center hole spacing (front flange/base)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Weight: 1.85kg (without accessories)
- Dimensions: 235mm(L) × 60mm(W) × 60mm(H) (max extended length)
- Rod thread: M10×1.25 (both ends)
- Piston speed: 50–800mm/s
- Protection class: IP54 (standard seals)
Precision dual-rod cylinder featuring micrometer-style stroke adjustment with lock nuts, enabling micron-level positioning accuracy. The symmetrical rod design eliminates lateral forces during operation, making it ideal for applications requiring balanced thrust and precise linear motion. Includes built-in magnetic piston for sensor compatibility.
- CNC machine tool clamping mechanisms
- Precision alignment systems in semiconductor manufacturing
- Automated packaging line product positioning
- Glass cutting equipment pressure control
- Robotic arm end-effector adjustments
Installation note:
For optimal performance, maintain 0.5–1mm clearance between rods and load during alignment.
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side loads exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SIJ40X125-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 125mm |
