Airtac SIJ40 Double Shaft Adjustable Cylinder SIJ40X125-50
2. Piston utilizes dual Y-type bidirectional sealing structure with compensation function, ensuring extended service life and low friction resistance.
3. Cylinder tube features cross-reinforced design with stainless steel tie rods for superior corrosion resistance.
4. Smooth and stable cylinder motion output.
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: SIJ40 **Key Technical Enhancements:** - Explicitly clarified "double rod" positioning in line with product naming conventions - Optimized sealing mechanism description to emphasize bidirectional functionality and wear compensation - Specified "cross-reinforced" to accurately reflect the structural advantage of the tube design - Added "customization" terminology to highlight configuration flexibility - Maintained consistent industrial terminology formatting throughout
AirTAC SIJ40X125-50 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ40X125-50
- Type: Double rod compact cylinder with adjustable stroke
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 125mm (±1mm adjustment range)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Rubber buffer with adjustable shock absorber
- Mounting style: Standard foot/axial mount (MF1) with 50mm center distance
- Port size: M5x0.8 (G1/8 optional)
- Rod diameter: 12mm (chrome-plated steel)
- Stroke adjustment: Mechanical stopper with ±1mm fine-tuning
- Weight: 2.5kg (without accessories)
- Dimensions: 210mm(L) × 80mm(W) × 80mm(H)
- Seal material: NBR with wear-resistant guide rings
- Protection class: IP54 (standard dust/water resistance)
- Piston speed: 50–700mm/s (lubricated condition)
High-precision dual rod cylinder featuring symmetrical force distribution and anti-rotation stability. The hardened aluminum alloy body with double O-ring seals ensures leak-free operation. Integrated stroke adjustment mechanism allows micron-level positioning through mechanical stoppers, ideal for repetitive precision tasks. Requires ISO VG32 hydraulic oil or equivalent lubrication.
- Precision alignment in semiconductor wafer handling
- Vertical lifting mechanisms in automated packaging lines
- Clamping fixtures for CNC machining centers
- Position control in pharmaceutical blister packaging
- Material transfer systems with space constraints
Installation tip:
Maintain 0.5mm minimum clearance between rods during parallel installation.
Use locknuts (included) for stroke adjustment fixation. Lubricate guide rods monthly
with ISO VG32 oil in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | SIJ40X125-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 125mm |
