Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-100S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-100S Double Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-100S
- Type: Double rod compact cylinder with position adjustment
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushion type: Rubber bumper (both ends)
- Mounting style: Basic type (no accessories) with 4x M5x0.8 tapped holes
- Port size: G1/8 (Rc1/8 optional)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Ambient temperature: -10℃ to 80℃
- Weight: 2.8 kg ±5%
- Dimensions:
- Total length (extended): 304 mm
- Body width: 60 mm
- Height (with rods): 70 mm
- Center-to-center rod distance: 40 mm
- ISO standard: 15552 compliant
Precision double-rod cylinder featuring dual-axis alignment capability and stroke adjustment mechanism. The symmetrical design provides balanced thrust force (calculated 196N at 0.5MPa) and enhanced lateral load capacity. Includes adjustable stroke stoppers with ±2mm fine-tuning range and hex-lock system. Compatible with auto switches (separate purchase).
- Precision fixturing in CNC machine tooling
- Parallel gripper mechanisms in robotic arms
- Vertical lift synchronization systems
- Packaging machine product alignment stations
- Semiconductor wafer handling equipment
Installation guidelines:
Maintain 0.5mm minimum clearance between rods during parallel installation.
Apply silicone-free lubricant (ISO VG32) every 500km stroke operation.
Use counterbalance valves when handling vertical loads over 15kg.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
