Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-10S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-10S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-10S
- Type: Double-acting dual rod cylinder with adjustable stroke
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable through stopper mechanism)
- Operating pressure: 0.1–0.8 MPa
- Port size: G1/2 (Rc1/2 optional)
- Cushioning: Adjustable rubber buffer on both ends
- Piston rod material: Chrome-plated carbon steel (Ø16mm x 2 rods)
- Barrel material: Anodized aluminum alloy
- Seal material: NBR (nitrile butadiene rubber)
- Temperature range: -20℃ to 80℃
- Weight: 3.8 kg (without accessories)
- Dimensions: 230mm(L) × 100mm(W) × 130mm(H) (at mid-stroke position)
- Mounting: Standard ISO 15552 foot mounting with 55mm spacing
- Repeat positioning accuracy: ±0.5mm
- Max thrust: 1570N at 0.6 MPa
High-rigidity dual shaft cylinder designed for precision alignment applications. Features twin piston rods for enhanced moment resistance (30% higher than single rod models) and integrated locknuts for stroke adjustment (±5mm fine-tuning). Includes built-in magnet for inductive sensor compatibility (NPN/PNP switch-ready).
- Precision clamping in CNC machining centers
- Vertical lifting mechanisms in automated warehouses
- Parallel gripper systems for robotic arms
- Position alignment in semiconductor wafer handling
- Press-fit operations in automotive assembly lines
Installation note:
Maintain 0.5mm minimum clearance between stopper nuts during adjustment.
Lubricate rod surfaces weekly with ISO VG32 hydraulic oil. Avoid side load exceeding 200N.
- Use with AirTAC MAL40x100L air cushion for vertical applications
- Pair with SCPM-00-25B magnetic sensor for position feedback
- Recommended air preparation: FRL-4000-04D filter regulator
| Property | Property Value |
|---|---|
| sku | SIJ50X100-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
