Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-20S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-20S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-20S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø50mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Port size: 1/4" NPT (M5 optional)
- Rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: Nitrile rubber (NBR)
- Weight: 2.45 kg ±3%
- Dimensions (L×W×H): 200mm × 72mm × 72mm (excluding rods)
- Rod diameter: Ø16mm (both rods)
- Stroke adjustment range: 0-100mm (mechanical stopper)
- Mounting style: Front flange with 4×M6 threaded holes
- Protection rating: IP54 (standard)
Precision dual-rod cylinder featuring micrometer-style stroke adjustment (±0.5mm repeatability) with locking mechanism. The symmetrical rod design eliminates lateral torque for high moment resistance (up to 35 N·m). Includes built-in magnetic sensor slot (M5x0.8 thread) for position feedback. Requires 5μm filtered air with ISO VG32 lubricant.
- Precision clamping fixtures in CNC machining centers
- Vertical lift mechanisms for robotic pick-and-place systems
- Parallel gripper actuation in packaging lines
- Position adjustment in semiconductor wafer handling
- Press-fit operations in automotive assembly
Installation note:
Maintain 0.05mm maximum misalignment during mounting. Lubricate rods weekly
in high-cycle applications (>500,000 cycles/month). Avoid side loads exceeding
150N. For vertical mounting, use counterbalance valves.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
