Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-20STC
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-20STC Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-20STC
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable)
- Operation: Double-acting
- Operating pressure: 0.05–0.9 MPa
- Piston rod material: Hard chrome-plated carbon steel
- Guide rod diameter: Ø20 mm × 2 pcs
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting type: STC series (standard trunnion with clevis)
- Port size: M5×0.8 (Rc1/8 adapter included)
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Use ISO VG32 or equivalent)
- Weight: 3.8 kg ±2%
- Dimensions:
- Length (retracted): 230 mm
- Width (body): 70 mm
- Height (with mounting): 108 mm
- Center-to-center guide spacing: 60 mm
Precision dual-axis cylinder with hardened guide rods for enhanced lateral load capacity. Features anti-rotation mechanism and 360° adjustable mounting positions through trunnion base. The T-slot design allows direct tooling plate attachment. Includes built-in stroke adjustment screws (±3mm fine tuning) and wear-resistant PU seals.
- Precision fixturing in CNC machining centers
- Vertical lifting mechanisms in assembly lines
- Position-locked clamping in welding jigs
- Material handling with side load requirements
- Packaging machine pusher mechanisms
Installation note:
Align guide rods parallel to motion direction. Apply thread locker to adjustment screws after final positioning.
Maximum allowable lateral load: 150N at mid-stroke. Lubricate guide shafts every 500km of travel.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-20STC |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
