Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-30S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-30S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-30S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø50mm (ISO 6432 standard)
- Stroke: 100mm (adjustable ±2mm via limit screws)
- Thread specification: M30×1.5 (both ends)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–700 mm/s
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting style: Basic type (no pre-mounted brackets)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy (anodized surface)
- Seal type: HNBR seals (-20℃ to 120℃)
- Weight: 3.2kg (without accessories)
- Dimensions: 200mm(L) × 70mm(W) × 70mm(H) (retracted state)
- Guide rod diameter: Ø16mm (dual chrome-plated shafts)
- Repeat positioning accuracy: ±0.1mm
- ISO standard: 6432/VDMA 24562
Precision dual-axis cylinder with mechanical stability enhancement, featuring twin guide rods that eliminate rotational movement. The stroke adjustment mechanism allows micro-positioning through hex-key adjusted mechanical stops. Ideal for applications requiring rigid linear motion and precise end-position control. Includes built-in magnet for sensor mounting (SIJ-M series sensors compatible).
- PCB board handling robots (anti-rotation critical)
- Glass panel polishing equipment vertical actuators
- Automated screw driving machines (Z-axis positioning)
- Semiconductor wafer transfer systems
- Precision stamping die alignment mechanisms
Installation protocol:
Mounting surface flatness ≤0.1mm/m. Lubricate guide rods with ISO VG32 hydraulic oil
before initial operation. Avoid side load exceeding 150N. For vertical installations,
use counterbalance valves (sold separately).
| Property | Property Value |
|---|---|
| sku | SIJ50X100-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
