Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-30SN
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-30SN Dual Rod Adjustable Cylinder Specifications
- Model: SIJ50X100-30SN
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø50mm
- Stroke: 100mm
- Adjustment range: ±15mm (30mm total)
- Rod diameter: Ø16mm (both rods)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Basic foot mounting (MF1) with side accessory holes
- Material: Aluminum alloy barrel, hardened chrome-plated rods
- Seal type: NBR seals with wear-resistant guide rings
- Weight: 3.8kg (without accessories)
- Dimensions:
- Total length (extended): 268mm
- Body length: 168mm
- Width (foot mounting base): 80mm
- Height (including rods): 62mm
Precision dual-rod cylinder featuring micrometer-style stroke adjustment with lock nuts, designed for applications requiring precise positioning repeatability (±0.5mm). The symmetrical rod configuration minimizes lateral forces during operation, making it ideal for alignment-sensitive installations. Includes integrated mounting slots for sensor attachment.
- CNC machine tool clamping mechanisms
- Automated assembly line positioning jigs
- Glass cutting equipment with variable sizing
- Packaging machine product height adjustment
- Robotic welding fixture positioning
Operation tip:
Always perform stroke adjustment at mid-pressure (0.3-0.5MPa) for optimal accuracy.
Lubricate adjustment threads monthly with ISO VG32 hydraulic oil.
Critical note:
Do not exceed 85% of maximum stroke during initial setup to preserve
cushioning effectiveness. Avoid side loads exceeding 30N on rods.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-30SN |
| Adjustable Stroke | 30mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
