Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-40
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-40 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-40
- Type: Double rod, adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Rod axis spacing: 40 mm
- Mounting types: Basic type (MF1), foot mounting (MP4), front flange (MF2)
- Port size: G1/8 (M5 optional)
- Material: Aluminum alloy cylinder tube, hard chrome-plated piston rod
- Seal material: NBR (standard), optional polyurethane
- Weight: 2.45 kg (without accessories)
- Dimensions: 302mm(L) × 90mm(W) × 55mm(H)
- Rod diameter: Ø16 mm (both rods)
- Maximum lateral load: 135 N
- Protection rating: IP54 (standard), IP67 optional
Precision dual-axis cylinder featuring synchronized rod movement and stroke adjustment via external locking nuts. The symmetrical design minimizes rotational torque during operation, making it ideal for applications requiring parallel motion control. Includes built-in magnet for sensor mounting and stainless steel guide shafts for enhanced rigidity.
- Precision alignment in semiconductor handling systems
- Parallel gripper mechanisms in robotic automation
- Vertical lifting platforms with guided stability
- Glass panel polishing equipment positioners
- PCB board press-fitting mechanisms
Installation note:
Ensure proper alignment of both rod ends before securing. Lubricate through air port using ISO VG32 turbine oil.
Maximum permissible misalignment: ±0.2mm between rod ends. Avoid side load exceeding 20% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
