Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-50
$88.16
Regular price
$95.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ50X100-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO15552 (formerly ISO6431) standard cylinder
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Use M6 class 8.8 or higher bolts
with spring washers. Lubricate rods with ISO VG32 hydraulic oil before initial operation.
Recommended cycle rate: ≤120 cpm (with cushioning engaged).
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-50 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-50 (Standard ISO 15552 compliant)
- Type: Double rod, adjustable stroke pneumatic cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable through built-in stoppers)
- Operating pressure: 0.1–0.9 MPa
- Dual rod diameter: Ø12 mm each
- Stroke adjustment: ±3mm precision via hexagonal locknuts
- Mounting type: Standard ISO 15552 mounting grooves (4xM6 threads optional)
- Port size: G1/8 (NPT1/4 adapters available)
- Cushioning: Adjustable air cushion at both ends
- Seal material: NBR + polyurethane composite
- Temperature range: -20℃ to 80℃
- Weight: 3.2 kg (including rods and mounting accessories)
- Dimensions:
- Body length: 200 mm (excluding rods)
- Rod extension: +100 mm (max stroke)
- Overall width: 68 mm (including mounting flanges)
- Height: 58 mm (cylinder body diameter)
High-rigidity dual rod cylinder featuring synchronized piston movement and anti-rotation design. The hardened chromium-plated rods (HRC 45-50) provide exceptional wear resistance in high lateral load applications. Integrated shock absorbers reduce end-impact noise to ≤75 dB(A).
Industrial Applications:
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for glass handling robots
- Simultaneous clamping in CNC fixture systems
- Position adjustment in semiconductor wafer stages
- Parallel motion systems for printing machinery
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Use M6 class 8.8 or higher bolts
with spring washers. Lubricate rods with ISO VG32 hydraulic oil before initial operation.
Recommended cycle rate: ≤120 cpm (with cushioning engaged).
Special adjustment feature: The "-50" suffix indicates dual 50mm external
adjustment collars permitting mid-stroke position locking. Rotate clockwise to decrease
effective stroke length (min. 20mm achievable).
| Property | Property Value |
|---|---|
| sku | SIJ50X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
