Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-50S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-50S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X100-50S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable ±5° rotation)
- Adjustment mechanism: Dual-axis fine-tuning via lockable hex nuts
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -10℃ to 80℃
- Port size: Rc1/4 (NPT1/4 optional)
- Cushioning: Adjustable rubber buffer at both ends
- Mounting style: Standard front/rear flange (MF1/MF2 compatible)
- Material: Aluminum alloy barrel, hardened steel rods
- Seal type: HNBR seals with wear-resistant guide rings
- Weight: 2.45 kg (without accessories)
- Dimensions:
- Extended length: 293 mm
- Body width: 68 mm
- Height with rods: 95 mm
- Mounting hole spacing: 60×60 mm
Precision dual-axis cylinder featuring ±5° angular adjustment capability through its unique twin-axis mechanism. The chromium-plated piston rods provide corrosion resistance, while the hexagonal lock nuts enable micro-adjustments (0.5° increments) during installation. Requires 5μm filtered air and monthly lubrication (ISO VG32 recommended).
- Precision alignment in semiconductor wafer handling
- Parallelism correction in CNC fixture systems
- Angular compensation for robotic end effectors
- Synchronized clamping in injection molding machines
- Conveyor tracking adjustment systems
Installation tip:
Always perform angular adjustment with cylinder depressurized. Use torque wrench (5-7 N·m)
for locking nuts to prevent axis drift. Maintain minimum 0.3 MPa pressure during fine-tuning.
Critical note:
Avoid side loads exceeding 150N. For vertical installations,
use counterbalance valves (sold separately). Replace guide rings every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
