Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X100-50SN
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X100-50SN Twin Shaft Adjustable Cylinder Specifications
- Model: SIJ50X100-50SN
- Bore size: Ø50mm
- Stroke: 100mm (adjustable)
- Rod diameter: Ø20mm dual shafts
- Operating pressure: 0.05–0.9 MPa
- Air port size: PT1/4 (G1/4 optional)
- Cushioning: Adjustable rubber buffer
- Operating temperature: -10℃ to 80℃
- Piston material: Die-cast aluminum alloy
- Rod material: Hard chrome-plated steel
- Seal type: NBR + PU combination
- Weight: 3.8kg (excluding accessories)
- Dimensions: 218mm(L) × 76mm(W) × 76mm(H)
- Mounting options: Front flange/Foot mount
- Protection rating: IP54 (standard wiper design)
High-precision dual-rod cylinder with mechanical stopper adjustment mechanism, featuring twin shafts for enhanced moment resistance and position stability. The integrated scale markings (±5mm adjustment range) enable micron-level positioning repeatability. Special anti-rotation design prevents shaft spinning during operation.
- Precision clamping in CNC machining centers
- Material handling with position-sensitive grippers
- Automated inspection equipment positioning
- Glass panel polishing machinery
- Parallel motion mechanisms in packaging lines
Installation note:
Use locknuts (M6×1.0) for stroke adjustment fixation. Lubricate guide shafts weekly with ISO VG32 hydraulic oil.
Avoid lateral load exceeding 200N. For vertical mounting, install air vents upward.
| Property | Property Value |
|---|---|
| sku | SIJ50X100-50SN |
| Adjustable Stroke | <50mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
