Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X1000-10
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X1000-10 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X1000-10
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø50mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable hydraulic buffer
- Port size: G1/2 (ISO228/1 standard)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR/PU combination
- Weight: 14.8kg ±2% (excluding accessories)
- Dimensions:
- Body length: 1180mm (stroke-dependent)
- Cross-section: 70mm(W) × 70mm(H)
- Mounting base: 125mm × 60mm
- Rod diameter: Ø20mm (dual rods)
- Max theoretical thrust: 1963N @ 0.5MPa
- ISO standard: 15552 compliant
- Protection rating: IP54 (standard seals)
High-precision dual rod cylinder designed for heavy-duty linear motion requiring exceptional rigidity and stroke adjustability. Features symmetrical force transmission through parallel rods, with mechanical end-lock adjustment system for precise stroke setting. Corrosion-resistant construction with integrated mounting slots for flexible installation.
- Automated material handling systems
- Precision press fitting operations
- Large-format CNC machine tool clamps
- Automotive assembly line positioning
- Glass manufacturing conveyor systems
Installation note:
Requires dual-side alignment during mounting. Lubricate rods with ISO VG32 hydraulic oil
before initial operation. Max lateral load capacity: 650N per rod. Stroke adjustment
must be performed with depressurized system.
| Property | Property Value |
|---|---|
| sku | SIJ50X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
