Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X1000-10S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X1000-10S Double Rod Adjustable Cylinder Specifications
- Model: SIJ50X1000-10S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø50mm
- Stroke: 1000mm (adjustable)
- Installation type: Basic type with fixed mounting
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: G1/8 (M5 optional)
- Rod diameter: Ø16mm (both rods)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Temperature range: -20℃ to 80℃
- Protection rating: IP54 (standard)
- Weight: Approximately 5.8kg (without accessories)
- Dimensions:
- Total length (L): 1230mm (stroke + end caps)
- Barrel outer diameter: Ø50mm
- Center-to-center rod spacing: 56mm
- Overall width: 82mm (including rods)
- Mounting base height: 12mm
Heavy-duty dual rod cylinder designed for precision linear motion in long-stroke applications. Features symmetrical force distribution through parallel rods, with 360° adjustable stroke limiters. Corrosion-resistant construction with integrated mounting slots allows horizontal/vertical installation. Requires 40μm filtered air with ISO VG32 lubricator (optional oil-free operation).
- Automated production line positioning systems
- Material handling equipment gates/doors
- Automotive assembly jig controls
- Packaging machine product stops
- CNC machine tool fixture actuation
- Conveyor system height adjustment
Installation note:
For strokes >800mm, use intermediate support brackets to prevent rod deflection.
Maintain 0.5-1mm clearance between stoppers and rod ends. Lubricate guide shafts
every 2,000km of travel. Avoid side loads exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SIJ50X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
