Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X1000-20
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X1000-20 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X1000-20
- Type: Double rod adjustable stroke cylinder (dual axis)
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable via mechanical stoppers)
- Rod diameter: Ø20 mm (both rods)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Fixed type (MF1) with front flange
- Port size: G1/4 (ISO228/1 standard)
- Seal material: Polyurethane (NBR optional)
- Protection rating: IP54 (standard wiper design)
- Weight: 8.7 kg (without accessories)
- Dimensions: 1180mm(L) × 75mm(W) × 75mm(H)
- Rod thread: M10×1.5 at both ends
- Max speed: 500 mm/s
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-rigidity dual rod cylinder designed for precision positioning in long-stroke applications. Features chromium-plated piston rods with hardened steel substrate (HRC 35-45) for wear resistance. The symmetrical dual-axis structure minimizes lateral torque deformation, making it ideal for applications requiring parallel motion stability.
- Automated material handling systems
- Precision press fitting operations
- Glass cutting machinery positioning
- Semiconductor wafer handling robots
- Automotive assembly line fixtures
- Large-format CNC router tool changers
Installation note:
Ensure proper alignment using alignment jigs during mounting.
For full-stroke applications exceeding 800mm, recommend adding intermediate support guides.
Lubricate rod bearings every 500km of cumulative travel.
- Loosen the four M6 locking screws on the stopper block
- Slide the mechanical stopper to desired position (±2mm fine tuning available)
- Retighten screws using cross pattern (8-10 N·m torque)
- Verify parallelism with dial indicator (max 0.1mm deviation)
| Property | Property Value |
|---|---|
| sku | SIJ50X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
