Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X1000-30
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X1000-30 Double Axis Adjustable Cylinder Specifications
- Model: SIJ50X1000-30
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Port size: Rc1/4 (NPT1/4 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Basic type (no built-in mounting)
- Rod end type: Female thread M12×1.25
- Seal material: NBR + PU combination
- Weight: 9.8 kg ±3%
- Dimensions (L×W×H):
- Extended length: 1370 mm
- Retracted length: 370 mm
- Body width: 76 mm
- Mounting height: 50 mm
High-rigidity dual-axis cylinder with stroke adjustment mechanism, featuring chromium-plated piston rods and aluminum alloy end caps. The twin-rod design provides enhanced moment resistance and precise linear motion. Includes magnetic piston for sensor compatibility and adjustable stroke locking collars with hex socket screws.
- Long-span material handling systems
- Precision glass panel positioning devices
- Automated welding equipment guides
- PCB board press mechanisms
- Solar panel array alignment systems
Installation note:
Requires dual-side support brackets (AVM-50 recommended) for full stroke operation.
Lubricate rod bearings every 500km of travel. Maximum side load capacity: 220N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SIJ50X1000-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
