Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X1000-30S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X1000-30S Dual Axis Adjustable Cylinder Specifications
- Model Code Breakdown: SIJ50-X1000-30S
- SIJ: Dual axis adjustable cylinder series
- 50: Cylinder bore diameter (φ50mm)
- X1000: Extended stroke length (1000mm)
- 30S: Standard switch type with built-in magnet
- Operating pressure range: 0.1-0.9 MPa
- Piston speed: 50-750 mm/s (optimal range 100-500 mm/s)
- Ambient temperature: -10℃ to 70℃ (no freeze)
- Cushioning type: Adjustable elastic cushion at both ends
- Rod thread: M14×1.5 (both ends)
- Mounting type: Horizontal/vertical with optional brackets (MFH style)
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated carbon steel (S45C)
- End caps: Die-cast aluminum
- Weight: Approximately 9.8 kg (calculated with 1000mm stroke)
- Dimensions:
- Length: 1236mm (stroke 1000mm + cylinder base length)
- Width: 72mm (including guide rods)
- Height: 72mm (square cross-section)
- Accessories: Includes mounting base plate, rod end nuts, cushion adjusters
High-precision dual-rod cylinder designed for heavy-duty linear motion requiring exceptional lateral load capacity. Features parallel chrome-plated guide rods (φ16mm) with adjustable stroke limiters. The through-shaft design eliminates rotation during operation, making it ideal for precision alignment tasks. Requires ISO 8573-1 class 3 lubricated air (40μm filtration).
- Automated palletizing systems for heavy payload positioning
- Precision glass panel handling in LCD manufacturing
- Vertical machining center tool changers
- Automotive welding fixture clamping mechanisms
- High-cycle packaging machine pusher assemblies
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Use flexible couplings when connecting to driven components.
Perform initial lubrication with ISO VG32 hydraulic oil before first operation. Regular maintenance every 500km of travel distance.
| Property | Property Value |
|---|---|
| sku | SIJ50X1000-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
