Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X1000-75
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X1000-75 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ50X1000-75
- Type: Double rod, adjustable stroke pneumatic cylinder
- Bore size: Ø50mm (±0.1mm tolerance)
- Stroke: 1000mm (adjustable in 1mm increments)
- Operating pressure: 0.1–0.9 MPa
- Piston rod diameter: Ø20mm (chrome-plated steel)
- Cushioning: Adjustable air cushion at both ends
- Port size: G3/8 (ISO standard)
- Mounting style: FA-type (fixed axis with front flange)
- Body material: Aluminum alloy (A6063-T5)
- Weight: 12.8kg (excluding accessories)
- Dimensions: 1180mm(L) × 72mm(W) × 72mm(H)
- Operating temperature: -10℃ to 80℃
- Seal material: NBR + PU hybrid seals
- Lubrication: Pre-lubricated (requires ISO VG32 replenishment every 500km stroke)
- Max thrust: 1570N @0.63MPa
- Repeat positioning accuracy: ±0.2mm
High-rigidity dual rod cylinder designed for precision linear motion in heavy-duty applications. Features stroke adjustment locks with graduated scales and anti-rotation guides for stable load handling. The symmetrical rod design minimizes lateral deflection during extended stroke operations.
- Automated palletizing systems requiring variable stacking heights
- Press brake tool positioning in metal fabrication
- Glass cutting machine X-Y axis drives
- Semiconductor wafer handling robots
- Vertical CNC tool changers
Installation notes:
Requires alignment within 0.05mm/m using laser measurement tools.
Mounting surface flatness must be ≤0.1mm.
Use M8x1.25 mounting bolts (grade 8.8 or higher) at 30Nm torque.
- Inspect rod wipers every 50,000 cycles
- Lubricate guide shafts with EP2 grease monthly
- Check cushion adjustment lock nuts for torque (15N·m) quarterly
| Property | Property Value |
|---|---|
| sku | SIJ50X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
