Airtac SIJ50 Double Rod Adjustable Cylinder SIJ50X1000-75S
2. Piston features dual Y-type bidirectional seals with self-compensation, ensuring extended service life and minimal dynamic friction
3. Cylinder tube with cross rib design and triple tie rods enhances corrosion resistance
4. Adjustable cushioning ensures smooth cylinder operation
5. Multiple cylinder specifications and mounting accessories are available to meet diverse customer requirements
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ50
AirTAC SIJ50X1000-75S Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ50X1000-75S
- Type: Dual-axis adjustable stroke cylinder (rodless type)
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting type: 75S - Front flange with side mounting holes
- Piston rod diameter: Ø16 mm (dual rods)
- Max speed: 500 mm/s
- Ambient temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Repeat accuracy: ±0.5 mm
- Allowable moment: 80 N·m (lateral), 40 N·m (vertical)
- Weight: 5.8 kg (excluding accessories)
- Dimensions: 1075mm(L) × 80mm(W) × 96mm(H)
- Port size: Rc1/4 (G1/4 optional)
- Material: Aluminum alloy body, chrome-plated piston rods
High-precision dual-rod cylinder engineered for heavy-duty linear motion with exceptional lateral load capacity. Features micrometer-style stroke adjustment (±5mm fine tuning) through external locking nuts. The 75S mounting configuration provides enhanced stability for vertical or inclined installations. Integrated magnet slots enable position sensing compatibility.
- Precision glass panel handling systems
- Automotive welding fixture positioning
- Large-format CNC router Z-axis drives
- Palletizing robot end effectors
- Semiconductor wafer transfer mechanisms
Installation note:
Maintain 0.3-0.5mm clearance between rods and guides during alignment.
Use locknuts with 15-20 N·m torque for stroke adjustment. Lubricate rods
monthly with ISO VG32 hydraulic oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SIJ50X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
